Data Sheet:

• Dimensions: 48 mm x 80 mm x 21 mm
• Weight (g): 142 g
• Maximum current (A): 160A
• SBEC (A) No (OPTO)
• Battery cells: 6s - 22.2V, 7s - 21.77V, 8s - 29.6V, 9s - 33.3V, 10s - 37V, 12s - 44.4V, 14s - 51.8V
• Connection: Supplied without plug

NEW 32-bit ZTW Mantis G2 160A HV ESC 6-14S OPTO for RC airplanes and helicopters.

The vents on both sides of the ESC and the unique fan shroud ensure improved heat dissipation. The special fan guard directs airflow from the fan into the interior of the ESC, which improves internal air circulation and dissipates more heat from the ESC. This significantly improves the ESC’s heat dissipation, allowing the ESC to operate more stably and run cooler in various harsh environments.

Through the use of imported IC components and advanced PCB manufacturing, the ESC features low heat generation and high current endurance, making the ESC more reliable and stable.

With the new, unique circuit design and improved algorithm, as well as the powerful 32-bit microprocessor, computing power is significantly improved, allowing the ESC to respond more quickly.

The new ESC supports motor rotation reversal.

Synchronous rectification significantly reduces controller heating, making the controller more energy-efficient.

Supports real-time data transmission: current, voltage, temperature, RPM, throttle, and ESC status. And you can check the data in real time using the app.

The ESC features a separate programming interface for connecting to an LCD programming board or an app adapter for parameter adjustment, making the process easier and more convenient.

Features:

• Super smooth and precise throttle response
• Higher driving efficiency and greater energy savings
• Two modes: normal and smooth acceleration
• Multiple protection functions: startup, overheating, undervoltage shutdown, overload, overcurrent, and signal loss.
• Reliable thermal overload protection
• Automatic throttle cutoff in case of signal loss
• Overheating protection: If the ESC temperature exceeds 110 degrees Celsius, the ESC will reduce output power to allow it to cool down.
• Signal loss protection: The ESC automatically cuts off power to the motor when it detects that the throttle signal has been lost for 2 seconds; the motor then emits a continuous beep.
• Supports high-speed motors and is compatible with most motors on the market.

Specifications:

• Continuous current: 160A
• Burst current: 180A
• Battery: 6-14S LiPo
• BEC output: No BEC. OPTO.
• Dimensions: 78.5mm x 53.5mm x 32mm
• Weight: 228g

Programming:

• Performed via the transmitter
• 4 different braking modes
• Battery types: NiCd/NiMH/LiPo/LiFe
• Low-voltage cutoff
• Low-voltage protection: 2.8–3.2 V
• Governor mode
• Frequency: 8 or 12 kHz
• LiPo: 6 to 14S or Auto
• Motor control: 0 to 30°

Downloads:

ZTW Mantis Manual EN
