High-performance ESC with 3D and 4D modes for any indoor model

This ESC, paired with the T-Motor AM40-1500KV, delivers plenty of power for any indoor model! Whether you’re using a 2S or 3S LiPo. You can switch between 3D and 4D modes with the push of a button.

Fast response time and a powerful BEC are further reasons to use this little monster of a ESC!

To enter 4D mode, simply press the button and hold it down for 10 seconds. You’re ready to fly in 4D mode.

Features
1. BLHel-S firmware, fast response time, excellent performance;
2. Automatic detection of throttle signal, support for Pulse Width Modulation (PWM) (1-2ms), Oneshot25 (125-250us), Oneshot42 (41.7-83.3us) and Multishot (5-25us);
3. Automatic braking for high efficiency. When the throttle is pulled down, the motor responds quickly to this change to slow down;
4. For racing drones with high-KV, high-power motors.
5. Aluminum alloy heatsink for cooling (16A/25A):
6. Supports4A@5.6VBEC;
7. Supports single-direction and dual-direction switching:

Technical Specifications
Model Number: AM16A 3D/4D
Current: 16A
Peak: 25A
BEC: Yes
BEC Current: 4A
BEC Voltage: 5.6V
LiPo: 2-4S
Weight: 8.5g
Size: 12x24x6.2mm
Application: 120g – 320g Fixed Wing

Instructions T-Motor F3P BPP-4D 16A ESC with BEC 2-4S LiPo
